Batch Fryer

Food Frying Machinery / Deep Fryer / Deep Frying Machine

Equipment Performance
The batch fryer uses an oil-water mixture technology, which extends the replacement duration of the edible oil. The deep fryer also has an automatic oil temperature controlling system, which slows the speed of edible oil carbonization, reducing the increase in the edible oil’s acid value. This significantly reduces fumes generated during the working process. The batch frying machine also features an over-heat alarm device and sensors to ensure the safety of the deep frying machine.

Model and Specification

Model Rated power (KW) Dimension (mm) Oil tank size (mm) Oil capacity (kg)
XD-300 4.5 380 x 600 x 900 300 x 440 x 280 20
XD-500 6 or 9 580 x 640 x 900 500 x 440 x 280 35
XD-650 12 730 x 640 x 840 650 x 440 x 280 45
XD-750S 4.5 / 6.0 840 x 640 x 900 300/450 x 440 x 260 48
XD-800 15 880 x 640 x 900 800 x 440 x 280 55
XD-1000 18 or 24 1080 x 650 x 950 1000 x 450 x 300 70
XD-1200 24 1280 x 650 x 950 1200 x 450 x 300 88
XD-1500 36 1580 x 650 x 950 1500 x 450 x 300 100
XD-2000 48 2080 x 600 x 950 2000 x 500 x 300 166
XD-3000 72 3160 x 760 x 1050 3000 x 600 x 400 400
